(WD Confidential)

WD Branded Products Retail Setup Sheet





My Net AC Bridge


Wired-to-wireless AC adapter

Headline Positioning


Take your home theater from wired-to-wireless at Gigabit AC Wi-Fi® speeds.

Ad Copy


  • 39 Character DMR copy - My Net™ AC Bridge, 4 Gigabit Ports, simple setup

  • 72 Character DMR copy - My Net™ AC Bridge, 4 Gigabit Ports, you can eliminate networking wiring, simple setup

Highlights


  • Eliminate networking wiring.

  • Stream entertainment at AC Wi-Fi speeds.

  • Simple push-button setup.

Keywords


WD, Western Digital, AC Bridge, wireless AC Wi-Fi Bridge, wireless-AC Bridge, wireless-N Bridge, Home Theater, AC Home Theater, network, home network, more coverage, Dual-Band performance, Dual-Band router, dual band router, wireless router, wireless, HD, HD router, HD dual-band router, Wi-Fi, AC WiFi, wireless-AC, entertainment router, streaming, HD streaming, High-Definition streaming, HD media streaming, stream, wireless range, range, superior range, range amplifying technology, Gigabit port, Advanced QoS, USB port, push button setup (WPS), multi Wi-Fi streams, DLNA, UPnP, antenna amplifiers, guest access, what is a network, USB, hard drive, what is Wi-Fi, which wireless router, wireless router, wireless internet, movie streaming, movie stream, streaming movies, streaming videos, wireless repeaters, repeater, video stream, USB adapters, network cable, wireless-G, wireless-N n, Gigabit Ethernet, router review, wireless extender, wireless internet range, wireless router for mac, extender, wireless range expander, Gigabit Wi-Fi, gigabit wireless, 5G Wi-Fi, 5G

Copy

Short


Convert 4 Ethernet-enabled devices and get blazing-fast AC Wi-Fi speeds for your home theater. Stream 3x faster than wireless-N. No software required. Simple two-button setup.

Medium


Convert up to 4 Ethernet-enabled devices like a smart TV, game console, Blu-ray disc™ player and media player and get blazing-fast AC Wi-Fi speeds for the ultimate HD entertainment experience. Stream 3x faster than wireless-N with more reliable coverage. Setup is simple with the push of two buttons. No software required.

Long


Convert up to 4 Ethernet-enabled devices like a smart TV, game console, Blu-ray disc™ player and media player and get blazing-fast AC Wi-Fi speeds for the ultimate HD entertainment experience. Stream 3x faster than wireless-N with more reliable coverage. Setup is simple with the push of two buttons. No software required.

Bring powerful AC Wi-Fi to your home theater.
Convert up to 4 Ethernet-enabled wired devices like a smart TV, game console, Blu-ray disc™ player and media player by plugging them into the bridge and get blazing-fast AC Wi-Fi speeds for the ultimate entertainment experience. Wireless-AC technology offers speeds up to 3x faster than wireless-N to maximize your entertainment.

Ridiculously fast speeds.
Experience the maximum AC Wi-Fi Gigabit speed performance on your home theater by pairing the My Net AC Bridge with a My Net AC1300 HD Dual-Band Router or other wireless-AC router. Start streaming 3x faster than wireless-N with more reliable coverage and high-definition quality.

Eliminate network wiring.
Plug up to 4 Ethernet-enabled devices into the Gigabit ports on the back of the bridge and avoid running network cables throughout your home. Sit back and enjoy seamless HD streaming at AC Wi-Fi speed easily and without cluttered wires. Also convert printers, computers and network attached storage devices like a My Book Live, to conveniently access and share throughout your wireless network.

Easy Push-Button Setup.
When we say simple setup, we mean it. No Software or PC required. Just push the WPS button on both the router and the bridge and it will automatically connect to the network. Plug your devices into the My Net AC Bridge and your home entertainment is instantly converted to Gigabit wireless speeds.

Add a My Net AC Router to achieve AC Wi-Fi speeds on your home theater.
To enjoy next-generation AC Wi-Fi speeds you must pair this bridge with an AC Wi-Fi router, like a My Net AC HD Dual-Band Router or other brands. The My Net AC Bridge is also compatible with all Dual-Band routers but will only produce speeds as fast as the router you have on your network.

Features


  • Next generation AC Wi-Fi

  • 4 Gigabit Ports

  • 3x faster than wireless-N

  • Simple setup. No Software needed.

Ideal for


  • Converting up to 4 Ethernet-enabled devices like a smart TV, game console, Blu-ray disc™ player and media player

  • Smooth, real-time streaming of HD movies, shows, games and more

  • Connecting to your home theater in just a few quick steps

Contents


  • 4-port My Net AC Bridge

  • AC adapter

  • Quick Install Guide

  • Ethernet cable

Compatibility


Supported browsers: Internet Explorer® 7, Safari 2, Firefox® 2, Google® Chrome™ 7 or higher

Web setup type in http://myacbridge or 192.168.1.240




Note: Compatibility may vary depending on user’s hardware configuration and operating system.

Product Dimensions

Width

6.98 in (177 mm)

Depth

2.48 in (63 mm)

Height

7.52 in (191 mm)

Weight

0.83 lb (0.38 Kg)

Product Specifications

Wireless speed

5 GHz band: 1300 Mbps*

Protocol(s)

5 GHz band: 802.11 ac, n, a

Wired speed

10/100/1000 Gigabit Ethernet

Ethernet ports

(4) LAN RJ45

WPS Pushbutton Setup

Yes

RoHS compliant3

Yes

Environmental Specifications

Operating temperature

0°C to 40°C (32°F to 104°F)

Non-op. temperature

–40°C to 70°C (-40°F to 158°F)

Packaging Specifications


English

EU

Metric

Retail package size




Face Width

12.52 in

318 mm

318 mm

Shelf Depth

3.0 in

76 mm

76 mm

Face Height

9.9 in

251 mm

251 mm

Retail package weight

2.02 lb

0.91 kg

0.91 kg

Master carton size

12.4 x 10.3 x 13.3 in

315 x 261 x 338 mm

315 x 261 x 338 mm

Master carton weight

8.89 lb

4.03 kg

4.03 kg

Pkgs. per master carton

4

4

4

Master cartons per pallet

36

30

36

Pallet load dimensions

48 x 40 x 45 in

1219 x 1016 x 1143 mm

1219 x 1016 x 1143 mm

Pallet weight

373.2 lb

145.1 kg

169.3 kg








Retail UPCs

US

WESTERN EUROPE

Order Number

UPC

Order Number

UPC

WDBMRD0000NBL-HESN

7 18037 80064 6

WDBMRD0000NBL-YESN

7 18037 80068 4





AUS/NZ

UK

Order Number

UPC

Order Number

UPC

WDBMRD0000NBL-AESN

7 18037 80063 9

WDBMRD0000NBL-UESN

7 18037 80065 3





CANADA




Order Number

UPC



WDBMRD0000NBL-VESN

7 18037 80062 2











Limited Warranty

Pan Americas

EMEA

Asia Pacific

1 year

2 years

3 years



Country Code

Made in China







For service and literature:

http://support.wdc.com
www.wd.com

800.ASK.4WDC North America

(800.275.4932)
800.832.4778 Latin America (Spanish)
+800.6008.6008 Asia Pacific
+800.ASK.4WDEU Europe (toll free where available)
+31.88.0062100 Europe, Middle East, Africa
Western Digital, WD, and the WD logo are registered trademarks in the U.S. and other countries; and My Net, and the FIT Lab logo are trademarks of Western Digital Technologies, Inc. Other marks may be mentioned herein that belong to other companies. Product specifications subject to change without notice.
© 2012 Western Digital Technologies, Inc.
All rights reserved.
Western Digital

3355 Michelson Drive, Suite 100

Irvine, California 92612
U.S.A.
4879-705232-A00 Oct 2012




Western Digital, WD, My Book, WD TV and the WD logo are registered trademarks in the U.S. and other countries; My Net, My Book Live, and WD TV Live are trademarks of Western Digital Technologies, Inc. The 5G Wi-Fi Logo is a trademark of Broadcom

Corporation in the United States and/or other countries. Internet Explorer, Windows, and Windows Vista are trademarks of Microsoft, Inc. Mac OS X and Safari are trademarks of Apple Inc. The Wi-Fi CERTIFIED Logo is a certification mark, and the Wi-Fi Protected Setup Identifier Mark is a mark of the Wi-Fi Alliance. The UPnP Logo is a registered trademark of UPnP Forum. Other marks may be mentioned herein that belong to other companies. Product specifications are subject to change without notice. Picture shown may vary from actual product.


* AC rates achievable only when used with any AC-capable router, like WD’s My Net AC HD Dual-Band Router. Maximum wireless performance rate derived from IEEE standard 802.11 specifications. Performance may vary based on broadband

Internet service, wireless performance factors and wired Ethernet performance of the device. Actual data throughput and wireless coverage may vary based on wireless network capacity, data throughput rate, range and coverage. Performance depends on

factors including distance from the access point, volume of network traffic, building materials and construction, operating system used, configuration of wireless products used, interference and other adverse conditions.
** Push-button setup works with devices that support Wi-Fi Protected Setup (WPS) like WD's My Net routers and others.

An active, customer-purchased, broadband Internet account is required for connecting this device and other connected devices. Some devices may require additional wireless adapters or an Ethernet cable to connect to this router.


© 2012 Western Digital Technologies, Inc. All rights reserved.



This document is the property of Western Digital Technologies, Inc. (WD) and may contain confidential, privileged, and/or non-disclosable information. Any distribution, reading, copying or use of this document without authorization by WD is strictly prohibited and may be unlawful. If you have questions regarding the distribution of this document, please contact your designated WD contact or WD account manager.
